PRODUCT
The future of livestock industry made with better technology
EGG GRADING
Egg Washer
The automatic egg sorting system has a sorting capacity of 12,000 to 70,000 per hour.
We strive to create the best products through continuous technology development in order to minimize the disturbance rate during the sorting process.
Egg sorting packaging
The automatic egg sorting system of Hanbat IoT Co., Ltd. allows you to check the sorting history anytime, anywhere through your smartphone or PC. The data collected from the automatic egg sorting system provides various statistical data and analysis such as the egg laying rate, egg weight, HH, and HD index.
Egg sorter Dimension
| Name | ability | Installation area | Power supply voltage | Power consumption | Weight | Packer line |
|---|---|---|---|---|---|---|
| HA-100 | 12,000/h(MAX) | 5M(W) X 4M(H) X 1.6M(D) | 220V 50hz or 60hz | 1Kw(11kw) | 800Kg~ | 3~5 line |
| HA-250 | 25,000/h(MAX) | 12M(W) X 6M(H) X 1.6M(D) | 380V 50hz or 60hz | 20Kw(1.5kw) | 2,500Kg~ | 4~6 line |
| HA-300 | 30,000/h(MAX) | 13M(W) X 7.5M(H) X 1.6M(D) | 380V 50hz or 60hz | 20Kw(1.5kw) | 2,800Kg~ | 4~6 line |
| HA-350 | 35,000/h(MAX) | 13M(W) X 7.5M(H) X 1.6M(D) | 380V 50hz or 60hz | 20Kw(1.5kw) | 2,800Kg~ | 4~6 line |
| HA-600 | 60,000/h(MAX) | 18M(W) X 10M(H) X 1.6M(D) | 380V 50hz or 60hz | 50Kw(3kw) | 7,600Kg~ | 8~12 line |
| HA-700 | 70,000/h(MAX) | 18M(W) X 10M(H) X 1.6M(D) | 380V 50hz or 60hz | 50Kw(3kw) | 7,600Kg~ | 8~12 line |
